Bihler mach 05 wire & strip former
What is for sale: Bihler mach 05 wire & strip former
BIHLER MODEL MACH 05 WIRE & STRIP BLANKER & FORMER*
Maximum Strip Width: 1.57"
Widening Up to: 2.36
Maximum Feed Pitch: 6.3"
Length of Die Set: 15.7" Max
Bending Slide Capacity: 5.6 Ton (per Slide)
Stroke of Slide: 1.97"
Maximum Feed Length of Gripper Feed: 7.88"
Central Mandrel: 1.97" Stroke (Positivley Controlled)
Press Capacity: 28 Ton
Press Stroke: .63"
Siemens Coros OP-15 CNC Control
(1) Primary Press Unit
(5) Multi Index Slide Units on Circular Turret
Coil-Mate Horizontal Rotary Feeder
Central Lubrication System
Pneumatic Clutch and Brake
AC Main Drive Vari-Speed Motor
Approximate Overall Dimensions: 90" L-R x 65" F-B x 90" H
Approximate Weight: 10,000 Lbs.
Serial Number: 26498 (New 1998)
P2 F.O.B. Elk Grove, IL - $195,000.00
* PRELIMINARY SPECIFICATIONS SUBJECT TO VERIFICATION
